Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: WEHO
  • Model Number: LRS-100-15
  • Output Power: 51 - 100W
  • Output Type: Single
  • Input Voltage: 110/220V
  • Output Voltage: 15v
  • Output Frequency: 47~63Hz
  • Output Current: 7A
  • Certification: CE ROHS
  • Warranty: 2 Years
  • Overload proctection: 110%~150%
  • Potection type: Hiccp mode,recobers automatically after condition recoverd
  • Setup rise time: 500ms,30ms/230VAC 500ms,30ms/115VAC at full lod
  • Hold up time: 55ms/230VAC ,10ms/115VAC at full lod
  • Working temperature: -30°C~+70°C
  • Overall dimension: 129*97*30mm
  • Safety standards: Meet ULGB4943 UL60950 EN60950
  • Weight: 0.34Kgs

Packaging & Delivery

Packaging Details: 40PCS/CARTON
Delivery Detail: 3-5days



ModelLRS-100-5LRS-100-12LRS-100-15LRS-100-24LRS-100-36LRS-100-48
Dc output voltage5V12V15V24V36V48V
Rated output current18A8.5A7A4.5A2.8A2.3A
Output current rage0-18A0-8.5A0-7A0-4.5A0-2.8A0-2.3A
Rated  Power90W102W105W108W100.8W110.4W
Wave and noise100mVp-p120mVp-p120mVp-p150mVp-p200mVp-p200mVp-p
Voltage ADJ. range4.5-5.5V10.2-13.8V13.5-18V21.6-28.8V32.4-39.6V43.2-52.8V
Voltage tolerance±2%±1%±1%±1%±1%±1%
Line Regulation±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%
Load Regulation±1%±0.5%±0.5%±0.5%±0.5%±0.5%
Efficiency86.0%88.0%88.5%90.0%90.5%91.0%
AC input voltage rangeAC85~264V 47~63Hz;120~373VDC(Withstand 300VAC surge for 5 sec.Without damage)
Input current1.9A/115V   1.2A/230V
AC INnrush currentCold-start  50A/230V
Overload proctection110%~150% Potection type: Hiccp mode,recobers automatically after condition recoverd
Over-voltage protection5.75-6.75V13.8-16.2V18.75-21.75V28.8-33.6V41.4-48.6V55.2-64.8V
Potection type :Shut down o/p voltage,re-power on to recover
Setup rise time 500ms,30ms/230VAC 500ms,30ms/115VAC at full lod
 Hold up time55ms/230VAC ,10ms/115VAC at full lod
Withstand voltage I/P-O/P:3.75KVAC,I/P-FG:2KVAC,O/P-FG: 1.25KVAC
Isolation resistance I/P-O/P,I/P-FG,O/P-FG:100M Ohms/ 500VDC /25°C/70%RH
Working temperature-30°C~+70°C
Overall dimension129*97*30mm
Safety standardsMeet ULGB4943 UL60950 EN60950
EMC standardsMeet EN55022,EN61000-3-2,EN61000-3-3,EN55024 GB9254 Class B
Weight0.34Kgs
